Weinger EY506 data acquisition module

2500 ZAR

Details: AD7606 data acquisition module with 8-path synchronization Adopts high-precision 16-bit ADC chip AD7606 8 analog inputs. 1M ohm impedance. [Without a negative supply, no front-end analog amplifier circuits can be directly connected to the sensor output] The input range of plus or minus 5V, plus or minus 10V. By IO control range. Resolution 16 The maximum sampling frequency 200Ksps. Supports 8 oversampling settings file (which can effectively reduce the jitter) Built-in benchmark Single 5V power supply SPI interface or 16-bit bus interface. Interface IO level can be 5V or 3.3V.
